TankBoost CAT5 450L

3.0 Bar Mains Water Booster System 450L Tank with Type AB Air Gap

TankBoost CAT 5 will boost multiple outlets, across multiple floors, all at the same time, in a mains-fed system.

TankBoost CAT 5 is an all-in-one unit made up of a water storage tank, fitted with type AB air gap, and an integrated submerged pump. Stored cold water is boosted by this integral submersible pump, delivering up to 3.0 Bar pressure and 80L/min flow.

The type AB air gap with weir overflow prevents the water from the tank going back into the mains water supply which makes TankBoost CAT 5 ideal for companies handling fluids that pose a serious health hazard.

Additional water storage units are available to increase capacity.

Showers

Taps

Combination Boiler

Unvented Cylinder

Where to buy

Features

TankBoost CAT5 improve flow in meat cutting room

Boost water pressure and flow

Delivers pressure up to 3.0 Bar and increases water flow up to 80L/min.

TankBoost submersible pump

Submersible pump

TankBoost features a high-quality, stainless steel pump.

TankBoost CAT5 features AB air gap diagram

AB backflow protection

The type AB air gap with weir overflow.

TankBoost cat5 feature boosting multiple outlets

Use multiple outlets at the same time

Showers, taps and other outlets can be used simultaneously.

Salamander Pumps 2 Year Warranty

Warranty

2 years warranty.

Compatability

CAT5 for pet grooming - dog shower

TankBoost CAT5 450L is suitable for commercial entities with a mains fed system, such as a combination boiler or unvented cylinder.

Toilet

Wash basin

Washing machine

Dishwasher

Instant electric shower

Thermostatic mixer shower

Drench shower head

Multi-function shower head

Body jets

Technical Details

    TankBoost CAT5 450L
TNK-450-SUBC5
General
Warranty 2 years
Noise Rating
dBA 44.7
Usable Water
Tank Size (litres) 450
Dimensions
Height (mm) 1670
Width (mm) 642
Depth (mm) 640
Weights
Empty Weight (kg) 67.0
Filled Weight (kg) 517.0
Pump
Pump Type Submersible Centrifugal Multi-Stage Pump
Pump Body/Impeller Stainless Steel
Enclosure Protection IPX8
Electrical
Power Supply 230V, 50Hz
Current (Full Load) 4.2A
Power Consumption 730W
Cable Length 8m (Plug not supplied)
Fuse Rating 5A
Connections
Inlet Connection 1/2" BSP Male
Outlet Connection 1" BSP Female
Performance
Maximum Pressure 3 Bar/300kPa
Maximum Flow Rate 80lpm
Protection
Type AB
Water Temperature
4°C - 20°C
Pressure Vessel
8L Vessel with 1.5 Bar Air Pre-Charge
What Is a Cat 5 water tank?

A Category 5 water tank features an air gap between the inlet and outlet, preventing any backflow of water from the tank or cistern into the mains water supply. These air gaps are Type AB which satisfies the applicable requirements of Water Regulations for Category 5 systems.

TankBoost CAT 5 is the mains water booster system is fitted with type AB backflow protection, making it suitable for commercial use where there is a risk of backflow contamination with fluid Category 5.

What is a Cat 5 tank used for?

Cat 5 water tanks are suitable for laboratories, chemical cleaners/contractors, butchery and meat trades, healthcare premises, abattoirs, dog grooming parlours, bin wash down areas for flats etc.

All the examples above carry the highest risk level of the most serious health hazard because of the presence of pathogens and radioactive or very toxic substances.

TankBoost CAT 5 water tank features an air gap between the inlet and outlet to ensure that the water in the tank or cistern does not flow back into the mains water supply.

What is Category 5 (CAT 5) water supply?

Fluid Category 5 (CAT 5) is characterized as a hazardous fluid due to its high concentration of pathogenic organisms, radioactive elements, or extremely toxic substances. This classification encompasses fluids containing faecal matter, human waste, animal waste, or pathogens from various origins, all of which pose significant health risks.

TankBoost CAT 5 satisfies the applicable requirements of Water Regulations for Category 5 systems. TankBoost CAT 5 is fitted with type AB backflow protection, making it suitable for use where there is a risk of backflow contamination with fluid Category 5.

What is a type AB air gap?

A Type AB air gap is a non-mechanical backflow prevention arrangement comprising of an inlet, receiving tank and unrestricted weir overflow (rectangular or non-circular).

A weir air gap (Type AB) is needed to stop contaminated water mixing with the mains water and sits directly below the water discharge point.

TankBoost CAT 5 water tank features an air gap between the inlet and outlet to ensure that the water in the tank or cistern does not flow back into the mains supply.

Can TankBoost be used at abattoirs, dog grooming parlours, bin wash down areas for flats etc.?

All the examples above carry the highest risk level of the most serious health hazard because of the presence of pathogens and radioactive or very toxic substances.

For all the applications listed above a TankBoost CAT5 would have to be used as it incorporates a Type AB tank air gap. A Type AB air gap Cat 5 TankBoost features an air gap between the inlet and outlet to ensure that the water in the tank or cistern does not flow back into the mains supply.



Can TankBoost water booster be used on combi boilers and unvented systems?

Yes, TankBoost is ideal for delivering pressure and the higher flow rates required to unvented systems up to 80 litres per minute. TankBoost can also be used to supply combi-boilers, however, combi-boilers may restrict the flow rate of hot water that can be produced.

Can you use TankBoost to pump hot water?

No, TankBoost has been designed for cold water only, it can however be used to increase cold water flow rates and pressure to any mains hot water system such as unvented cylinders and combi boilers.

What pipework connections does the TankBoost have?

All TankBoost units have a ½” brass male inlet connection and 1” female outlet. It is recommended to have 28mm diameter pipework from the TankBoost so as not to restrict the potential flow rates from the unit. This can then be reduced to 22mm or 15mm pipework closer to the outlets.
